2 IN 0 - 10,000 PSI TYPE E MODLE 8 STANDARD SERVICE PRESSURE GAUGE W/ 1502 CONNECTION

The OTECO Pressure Gauge offers high accuracy and dependability for your standpipe, mud pump, and other drilling and production applications where precision pressure measurements are required.

Features:

All pressure gauges have a built-in dampening mechanism to minimize wear and mechanical shock.
In addition, the heavy-duty seals restrict line fluid from entering the gauge mechanism.
The gauge mechanism itself is surrounded by a special oil providing resistance to extreme temperatures, as well as vibration and shock.
For additional safety, a low-pressure plug is installed to prevent gauge case and lens damage.
All gauges are available for standard, saltwater, and sour gas.
Manufactured, assembled and calibrated in the Oteco Houston, Texas, USA facility ensuring quality parts for accuracy and dependability.
Specifications:

Trim: Standard
Dial Face Type: Standard
Dial Face Units: PSI
Pressure Range: 0 - 10000
Sub End Connection: Union: 2FIG1502M
Dial Case: 8-1/8 Inch Diameter
Height: 13-1/4 Inch
Temperature Rating: -20°F to 250°F
Manufacturer Description: PG,8SD,PSI,S10K,2FIG1502M
